Item Parameter

C2

C3

Unit

Rated load (Emax):

20kg~470t

kg,t,klb

Maximal numbers of load cell verification Intervals (Nlc):

2000

3000

d

Minimum load cell verification intervals Intervals ( Vmin):

0.02

0.01

% of rated load

Sensitivity(Cn ):

30,000 o r 100,000

mV/V

Combined error:

0.027

0.015

-% of rated output

Temperature effect on sensitivity(Tkc):

0.0024

0.0012

=% of rated output/

Temperature effect on zero balance(Tk0):

0.002

0.0008

-% of rated output

Res olution of A/D (fo r tes t lo ad):

24 (at 1 Hz)1.0

Bit

Res olution of A/D (fo r tes t temperature ):

8 (at 1 Hz)

Bit

Measu ring rate:

50/25

/Sec

Baudrate:

9600/19200

Bps

Filter mode 1:

3~0.05(Low pass filter)

HZ

Filter mode 0:

8~3(Low pas s filter)

HZ

Zero b alance:

1.0

+% of rated output

Ins ulation res istance:

≥5000

MΩ (Mega-Ohms)

Safe overload:

150

% of rated capability

Ultimate o verload:

300

% of rated capability

Operating tem peratu re range:

-20~+70/-20~+160

℃/ °F

Rec ommend excitation:

7~ 12

V(Only DC)

Maxim um exc itation:

15

V(Only DC)

Material of ela sto mer:

A lloy ste el / Stainless stee l

Pro tec tion cla ss:

IP67/IP 68

Citation:

OIM L R60 / GB7551-1997
